2 megapixel IP dome camera 2.8-12mm lens

3.9/5 rating (7 votes)

The ED2023W3-E is an outdoor vandal-proof IP dome camera which can deliver high definition 2 megapixel resolution images (1080P, supporting H.264 at 30fps). This camera adopts Sony Exmor progressive scan CMOS image sensor for offering outstanding images at 2~3 times the resolution of standard surveillance cameras. This camera has built-in removable IR-cut filter to provide true day/night function. This model supports dual streaming technology and dual codec encoding (H.264, MJPEG).

This latest design vandal-resistant IP dome camera comes with Sony’s latest Exmor IMX222 CMOS image sensor. The IMX222 delivers without doubt outstanding quality especially under low lighting conditions.  As you can see from the image above, the Sony Exmor is the ideal image sensor to select when looking at both quality and reliability. It utilizes latest 1080P Hisilicon Hi3516C as SoC for video signal processing, this powerful chipset can support 3D-NR noise reduction and BLC, HLC, wide dynamic range features which can significantly enhance the overall image quality.  It's equipped with 2.8mm - 12mm vari-focal lens to allow user adjust its field of view. Included 30pcs infrared LEDs permit camera to capture images under complete darkness, additionally IR range reaches up to 20 meters at night vision mode.

Key Features

  • 2 megapixel resolution, 1920x1080P@25/30fps
  • 1/2.8-type progressive scan Exmor CMOS sensor(IMX222)
  • Impressive vandal-resistant design
  • Exmor technology offers great low illumination performance
  • Low illumination Color 0.01Lux@F1.2, B/W 0 Lux@F1.2
  • Hisilicon Hi3516C SoC processor
  • 3D-NR, BLC, HLC, wide dynamic range
  • Motion detection & privacy mask
  • Built-in 2.8-12mm vari-focal lens
  • Dual streaming capability
  • Equipped with 30pcs IR LEDs
  • IR range 20 meters
  • Supports WEB Configuration,IE Surveillance;
  • Supports OSD,Chroma,Brightness,Saturation,Electric Zoom
  • IP66 rated weatherproof design
  • Suitable for both indoor/outdoor installation
  • Working voltage DC12V
  • Local on-board storage (optional)
  • Power over Ethernet (optional)

1080P megapixel resolution

This camera is able to provide you high definition images at real time frames per second (fps). The megapixel resolution gives the user a greater number of pixels to work with. Full HD 1080P resolution allow this camera to work with your full HD video surveillance which can offer you greater image detail.

IP Camera 1080P Resolution

Remotely monitoring

Featuring an advanced web-server, allowing maximum ten users online to simultaneously access the camera through any internet browsers or Unifore IP camera client software, as well as smartphone apps.

Remote view from PC andsmartphone

Smart event detection

With advanced video smart analysis function, support motion detection, alarm input and system event. Integration solution including e-mail out notification and audio output, alarm relay output, ftp upload motion detection recording.

MicroSD/SDHC SD card slot on IP Camera

On-board Recording/PoE

As optional functions, this camera features on-board storage via a SD card slot. The SDHC card support up to 32GB storage capacity for local video recording. Additionally, user can choose to add PoE function which allow camera to work with single Ethernet cable, which in-turn reduce the cost for cost-effective video surveillance solution.

Get our latest price list

Subscribe to get the latest updates.

Your email address will never be shared with any 3rd parties
and you will receive only the type of content for which you signed up.

Technical parameter

Model No. ED2023W3-E
Camera Type IP  Vandal-Resistant Dome Camera
System Embedded RTOS design
Camera Effective Pixels 2.0 Mega Pixels
Main stream:1920*1080;1280*720
Sub stream:704*576
Frames Rates PAL:30/25fps(1920*1080)/(1280*720)
NTSC:30fps(1920*1080)/(1280*720)
Image Sensor 1/2.8"Progressive Scan CMOS Image Sensor (Sony Exmor IMX222)
Approx. 2.43M pixels resolution (1080P)
DSP Dual core   32-bit DSP Dual core
(Hi3516)
Min. Illumination Color: 0.01Lux @(F1.2,AGC ON), 0 LUX with IR
B/W 0.001 Lux @ (F1.2,AGC ON), 0 LUX with IR
Adjust Parameters DWDR, BLC, DNR, AE, AGC, Day&Night, Mirror,Flip,etc.
Video Compression H.264 Main profile
Stream support dual stream,AVI format
Bit Rate support 0.1M ~8Mpbs bit rate adjustablesupport 0.1M ~8Mpbs bit rate adjustablesupport 0.1M ~8Mpbs bit rate adjustable
Frame Rates support 1~30fps adjust support 1~30fps adjust support 1~30fps adjust
Audio Input and output 1CH  input( microphone),1CH   output( Speaker&microphone) Optional
Compression G.711 compression,support two-way audio intercom,support audio and video synchronized   output
Alarm Types Motion Detection, Video Blind , Video Loss
Network WEB Browser Support   WEB   remote   config( IE, Safari, Google Chrome, Firefox etc.)
Smart Phone Mobile remote Monitoring (iPhone, Android, Windows Mobile, BlackBerry,Symbian)
CMS Software Uniform CMS Software(multiple   devices   management   system)
Cloud P2P www.p2pipc.net,MYEYE platform and other program,Offer SDK
Network 1   *   RJ45,10/100M,Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP
ONVIF Support (ONVIF 2.0)
POE Support(optional)
WIFI N/A
General Language 20 kinds of languages such as English, Finnish, French, German, Greek,Italian, Japanese, Polish, Portuguese, Russian, Spanish, Thai,   S-Chinese, T-Chinese and Turkish
IR Cut Filter Set of double light switch IR-CUT filter
Lens Mount Varifocal Lens 2.8-12mm(2MP)
Infrared Luminary 30pieces IR-LED
Infrared Wavelength 850 nm
Illuminate Distance More than  20 M
Waterproof Criterion IP67
I/O Connector 1*DC Connector ,1* RJ45(10/100M Network)
Supplied Voltage DC12V/PoE(802.3af/820.3at)
Power Consumption IR On: 600mA max., IR Off: Less than 200mA
Working Environment -10°C~+60°C, 10%~90% ( Built in Heater being optional added for environment lower than -20° )
Dimensions 200*100*85mm
Weight 1.5kg
